MADE IN USA
Free ShippingProduct Specifications for Odyssey ODS-AGM28 Extreme Powersport Battery (PC925L)
| BM Part #: | PC925L |
|---|---|
| Made In: | U.S.A. |
| Battery Polarity: |
|
| Voltage: | 12 Volt |
| Capacity: | 28 Ah |
| Type: | AGM |
| Length: | 6.44" |
| Width: | 6.75" |
| Height: | 4.88" |
| Cold Cranking Amps: | 330 CCA |
| Shipping Weight: | 27.00Lbs |
| Warranty: | 2 Year (Warranty Info) |
Additional Specs:
- 330 CCA, 480 MCA, 610 HCA
- 900 Cranking Amps for 5 Seconds
- 53 Minute Reserve Capacity
- Cycle life @ 77° F 400 at 100% DOD
- -40° F to 140° F Temperature Range
- Also known as: PC925L-A and PC925L-P
- Replaces 278001763, 278001882, 278001882, 515176151, 53030, 52515, 66010-97C
- More Specs: (Adobe PDF)
- Catalogue number 0765-2029
- Made in the USA
- The Odyssey L Terminal Adapters may be required by some models to connect to the Odyssey battery. (Sold separately)
- For Maintaining This Battery: The Odyssey OBC-6A charger can be used.
- For Ongoing Deep Cycle Recovery: The Odyssey OBC-12A charger is recommended.
Odyssey trademark is the property of Enersys and affiliates.
- Made in the USA. Why it matters:
- Superior craftmanship; rigorously tested; high-quality parts.
- Better warranty
2 Years:- Auxiliary Power Unit (APU)
- Non-engine Start Cycling Applications.
- PowerSports Applications.
- Commercial, Industrial, Marine and Automotive Applications
- Longer service life
With 3-10 years of service life, ODYSSEY batteries save consumers time, money, and aggravation. - Longer cycle life
70% longer cycle life compared to conventional deep cycle batteries - up to 400 cycles at 80% depth of discharge - high stable voltage for longer periods of time. - Longer shelf life
Can be stored on open circuit (nothing connected to the terminals) without the need for recharging up to 2 years or 12.00V, whichever occurs first. - Faster recharge
The highest recharge efficiency of any sealed lead battery on the market - capable of 100% recharge in 4 - 6 hours. - 2 Batteries in 1
The characteristics of two separate batteries are combined in one box. It can deep cycle (be recharged) as well as provide enormous cranking power. - Superior cranking
The 5 second cranking power of Odyssey batteries is double to triple that of equally sized conventional batteries, even when the temperature is as low as -40°C (-40°F). - Mounting flexibility
Non-spillable design - can be mounted on any side in any position except inverted. - Vibration resistance
Design protects against high impact shock and mechanical vibration - a common cause of premature battery failure. - Extreme temperature tolerance
Operating temperatures from -40°C (-40°F) to 45°C (113°F), for models without a metal jacket and from -40°C (-40°F) to 80°C (176°F) for models with a metal jacket. - Totally maintenance free
No need to add water, ever! Drycell design with resealable venting system. - Improved safety
US Department of Transportation classified as a 'non-spillable' battery. No acid spills, no escaping gases.
Product Description
New! Odyssey PC925 with positive terminal reversed.
- 3 to 10 year service life, when properly maintained.
- 99.9% pure lead providing minimal plate corrosion
- Explosion proof
- Corrosion proof
- 2 to 3 times the cranking power of equivalent size battery
- Spill and leak proof
- Superior vibration resistance
- Fully Charged out of the box
- When fully charged can be stored for up to 2 years at 77° F
- May be installed on its sides at any angle without sacrificing performance attributes
- 2 Year Full Powersports Warranty
- Same battery is Odyssey PC925L-A and PC925L-P
2 Batteries in 1
The Odyssey PC925 battery combines in one box the characteristics of two separate batteries. It can deep cycle (be recharged) as well as provide enormous cranking power.
Military Grade
Only Hawker Odyssey batteries are based on the same battery technology offered by Hawker to the military for aircraft and tank batteries. Odyssey batteries are of military grade and have endured rigorous tests that demonstrate their overall ruggedness and exceptional tolerance of mechanical abuse.
Superior cranking and fast charge capability
The 5 second cranking power of Odyssey batteries is double to triple that of equally sized conventional batteries, even when the temperature is as low as - 40° C. Also, with simple constant voltage charging (alternator or independent charger), there is no limitation on the inrush current, so the user is assured of a fast charge.
Specs:
- Length 6.5 in.
- Width 4.91 in. (Depth)
- Height 6.88 in.
- Drycell Battery
- NO METAL JACKET
- Screws Included
- 12 Volt
- 26 Ah @ 10hr rate
- 330 CCA
- 480 MCA
- 610 HCA
- 900 Cranking Amps for 5 Seconds
- 53 Minute Reserve Capacity
- Cycle life @ 77° F 400 at 100% DOD
- -40° F to 140° F Temperature Range
- New! PC925 with positive terminal reversed.
- Catalogue Number 0765-2029
- More Specs: (Adobe PDF)
Note: Please check dimensions and terminal configuration to ensure this is the proper battery for your application.
 | Tech Tip: Special InstallationsMounting flexibility is one of the Odyssey battery's strongest features. It may be installed in just about any orientation (the only exception being inverted) without sacrificing any of its world-class performance attributes. Have no fear about acid spillage-- the battery recycles internal gas during operation/charging and the valve regulated design eliminates the need for an acid vent tube. All in all, this offers two awesome benefits:
|
Cross Reference
Customer Reviews
Put a PC925L in my 2004 FHLTPI 14 years ago, it still works, the Kubota yard tractor needed a batter so I moved it from the harley road king to the tractor and bought a new one for the harley. Have never had an issue with the Odyssey.
Love the battery, but installed on its side necessitates the use of the additional "L" adapters to connect. Once the heavy battery is dropped into its location, you need to use nuts, bolts, and tiny lock washers to connect the cables. Unfortunately, there's not enough remaining space to get the small bolts started into the nuts. It took me 3 hours, liberal cussing, and needle nose pliers to hold the nuts while using my old Philips head bolts with a screwdriver to try to start them into the nuts. Recommend purchasing the top terminal ODS-AGM30L battery for ease of installation even though it costs a bit more, but since you won't need the extra cost "L" adapters, the cost is about the same.
Excellent battery, fast shipping would highly recommend battery mart for all batteries.
Best bang for your buck!! Last one I bought lasted me 9 years,11 months and 2 weeks! How do you argue with that?
Great power to start my road glide. Best price around.
I bought this battery on 7/17/2014 it has lasted till 8/21/2022 with out any trouble of any kind. Well worth the money I payed.
Used on my 04 boss hoss trike working like a champ.
This so much great price &
Fast delivery.
