Product Specifications for Odyssey PC1700 Battery
|BM Part #:||PC1700|
|Cold Cranking Amps:||810 CCA|
|Warranty:||2-3 Year (Warranty Info)|
- 810 CCA, 1175 MCA, 1325 HCA
- 1550 PHCA (Cranking Amps for 5 Seconds)
- 142 Minute Reserve Capacity
- Cycle life @ 77° F 400 at 100% DOD
- -40° F to 140° F Temperature Range
- Stinger Power2 SP1700 equivalent
- Replaces 0771-2021
- More Specs: (Adobe PDF)
- Catalogue number 0765-2021
- Made in the USA
Note regarding below charger: Both sets of leads will need to be used for a single PC1700 battery to properly charge the battery.
Odyssey trademark is the property of Enersys and affiliates.
- Better warranty
- Auxiliary Power Unit (APU)
- Non-engine Start Cycling Applications.
- PowerSports Applications.
- Commercial, Industrial, Marine and Automotive Applications
- Longer service life
With 3-10 years of service life, ODYSSEY batteries save consumers time, money, and aggravation.
- Longer cycle life
70% longer cycle life compared to conventional deep cycle batteries - up to 400 cycles at 80% depth of discharge - high stable voltage for longer periods of time.
- Longer shelf life
Can be stored on open circuit (nothing connected to the terminals) without the need for recharging up to 2 years or 12.00V, whichever occurs first.
- Faster recharge
The highest recharge efficiency of any sealed lead battery on the market - capable of 100% recharge in 4 - 6 hours.
- 2 Batteries in 1
The characteristics of two separate batteries are combined in one box. It can deep cycle (be recharged) as well as provide enormous cranking power.
- Superior cranking
The 5 second cranking power of Odyssey batteries is double to triple that of equally sized conventional batteries, even when the temperature is as low as -40°C (-40°F).
- Mounting flexibility
Non-spillable design - can be mounted on any side in any position except inverted.
- Vibration resistance
Design protects against high impact shock and mechanical vibration - a common cause of premature battery failure.
- Extreme temperature tolerance
Operating temperatures from -40°C (-40°F) to 45°C (113°F), for models without a metal jacket and from -40°C (-40°F) to 80°C (176°F) for models with a metal jacket.
- Totally maintenance free
No need to add water, ever! Drycell design with resealable venting system.
- Improved safety
US Department of Transportation classified as a 'non-spillable' battery. No acid spills, no escaping gases.
ODYSSEY Extreme Series Battery Model PC1700
(internal threaded brass terminals with M6 SS bolts)
Whether for everyday or emergency use, today's vehicles are loaded with more electronics than would have been imaginable just a few years ago. ODYSSEY batteries have been designed to keep up with the changes. Because their plates are made of pure virgin lead (unlike the lead alloy in most batteries), we can pack in more plates. And more plates mean more plate surface area, and much more power - twice the overall power and three times the life of conventional batteries - up to 400 cycles at 80% depth of discharge!
ODYSSEY batteries deliver the massive starting power, rapid recovery, and amazing deep cycling capability that today's vehicles demand.
