Product Specifications for Dakota Lithium 72 Volt, 55 Ah LiFePO4 Deep Cycle Battery
| BM Part #: | DLITH-72V55 |
|---|---|
| Brand: | Dakota Lithium |
| Voltage: | 76.8 Volt |
| Capacity: | 55 Ah |
| Terminals: | M8 (0.312") |
| Type: | LiFePO4 |
| Length: | 20.5" |
| Width: | 10.5" |
| Height: | 8.62" |
| Shipping Weight: | 88.10Lbs |
| Warranty: | 11 Year (Factory Direct) |
| Rechargeable: | Yes |
- Up to 80% capacity for 2,000 cycles.
- Includes an active BMS (Battery Management System) that handles cell balancing, low voltage cutoff, high voltage cutoff, short circuit protection and temperature protection.
- Lithium Iron Phosphate: the safest lithium battery chemistry. Generates significantly less heat the other lithium chemitries, such as Lithium Ion found in many cell phones.
- No thermal Runaway: Dakota lithium cells are extremely stable and do not produce the oxygen needed to aid thermal runaway. Unlike other lithium battery chemistries, these will not result in catastrophic meltdown.
- 100% cobalt free. NCM and other lithium ion chemistries that contain rare earth elements such as Colton or Cobalt product oxygen and toxic fumes when ruptured. Dakota lithium does not contain rare earth elements, does not product oxygen, or is prone to fire.
- IP65 rated. Water-resistant, dust proof, and splash proof.
- Meets UNI 38.3 standards. Cells are UL1642 certified and have been tested per IEC62133 standards. Meets all US and International regulations for air, ground, train, and marine transport.
Product Description
Built Dakota tough, this single 72V (volt) 55Ah (amp hour) battery will power your passions from morning to night. Engineered with Lithium Iron Phosphate (LiFePO4) technology this battery has three times the power, one third the weight, and lasts 5 times longer than a set of lead acid batteries – providing exceptional lifetime value. Built as a drop in replacement for 72V electric vehicles, 72V golf carts, and 72V electric outboard motors. The exceptional energy density makes this an excellent choice for vehicles where weight is at a premium — one single 72V 55Ah Dakota Lithium battery weighs 1/5 as much as a set of lead acid batteries. Enjoy increased performance, speed, and handling for 72V golf carts, people movers, and neighborhood electric vehicles.
To increase your driving range link multiple units in parallel. For vehicles with higher amp motor controllers two or more batteries may be required. For motor controllers with 100A-250A two units are recommended. Motor controllers with 250A-350A three units are recommended. For example, an EZGO 72V Freedom has a 350A motor controller and requires 3 units in parallel. Most 72V golf carts can fit 3+ units in the battery compartment. For other electric vehicles measure the size of your battery compartment and compare to the length and width of the battery.
Exceptional reliability with 5X the lifespan of traditional lead acid or AGM batteries. Backed up by a best in class 11 year warranty. Go further, play harder, and last longer with Dakota Lithium.
