Odyssey PC1500DT Battery

BATTERY DESIGN

• Odyssey PC1500DT Battery
• Absorbent glass mat (AGM) technology
• 12V battery pure lead VRLA
• SAE Group 34/78 footprint - dual purpose
• Rugged construction
• Top tin plated brass SAE terminals and GM side terminals
• Can be mounted in any orientation except inverted
• Lifting handle
• US DOT and IATA certified non-spillable
• Shipped fully charged - just install and go!
• Container and cover made from oil resistant plastic
• Made in the USA

PERFORMANCE FEATURES

• PHCA: 1,500A at 80° F (27° C) for 5 seconds
• CCA: 850A at 0°F (-18° C)
• CA/MCA: 1,050A at 32° F (0° C)
• HCA: 1,250A at 80° F (27° C)
• Reserve capacity: 125 minutes
• Short circuit current: 3,100A
• 62 Ah @ 10hr rate
• Deep cycling capability: 400 at 80% DOD
Typical service life: 3 to 10 years, when properly maintained.
• Operation temperature range: -40° F (-40° C) to 176° F (80° C)

Dimensions

• Length: 10.85"
• Width: 6.99"
• Height: 7.82"

Warranty

4 Year Full Replacement
